Explosion-proof Rail Transfer Cart

This explosion-proof rail transfer cart is powered by cable reels consists of a transfer system consisting of two track cars rigidly connected by traction rods. One transport cart is powered and the other rail transfer trolley is not powered at all. Mainly used for transporting steel structures in paint spraying rooms, for the safety of transporter’s use, powered cart will push non powered track transfer trolley to transport goods to the paint spraying room, and then powered transport platform will detach from the non powered rail transport vehicle.

Send Inquiry

Product Introduction

Introduction

The Explosion-proof Rail Transfer Cart is a specially designed industrial vehicle for the safe transport of heavy loads in potentially explosive environments such as chemical plants, oil refineries, or mines.

Main advantages about rail transfer cart

Explosion-proof design

Certified motors, electrical components, and control systems are protected against sparks and overheating, ensuring safe operation in hazardous environments.

Multiple power supply options

Available in battery-powered or cable-powered configurations suitable for explosive environments.

Safety features

Our products are equipped with an emergency stop button, overload protection, anti-slip casters, and can be optionally equipped with alarms or limit switches.

Flexible control methods

Can be operated manually, remotely, or through fully automated integration with production systems.

Customization options

Load Capacity
Customizable to handle loads from a few tons up to 50 tons or more, depending on operational needs.

Rail Layout & Dimensions
Adaptable to existing rail systems, with custom track length, width, turning radius, and curve design.

Control Options
Manual pendant, wireless remote control, or fully automated operation integrated with production lines.

Speed & Movement Control
Adjustable speed settings and smooth start/stop profiles for safe and efficient load handling.

No.	Item	Specifications
1	Model	KPX-8T
2	Rated Loading capacity(T)	8
3	Ground clearance	50-100mm
4	Table size(mm)	30002000/15001500
5	Cart height(mm)	500
6	Operation method	Remote control & Wire Hand pendant
7	Rail center distance(mm)	1435
8	Rail Model	P18
9	Speed(m/min)	0-20
10	Movement Direction	Consistent with the length direction of trolley platform
11	Wheel quantity	4
12	Brake mode	Electromagnetic brake
13	Power supply	Cable drum powered
14	Protective device	Audible and visual alarm lamp, emergency stop button
15	Explosion-proof device	ExdllBT4
16	Other functions	Equip with lifting holes, battery status etc.
17	Move Way	Forward,backward
18	Flat car's protection	Overvoltage, undervoltage, overcurrent protection etc.
